Walvoil CG 4CAV70 Valve Cable - Dual Swivel
- SKU:
- J-4CAV70-10
- Availability:
- 1 - 4 Business Days
Description
No Returns Accepted | This cable is built to order so please select carefully.
Features:
- Equivalent to CG 4CAV70
- Compatible with Joystick 3335
- Maximum load: in traction 1450 N - 340 lbf | in compression 880 N - 198 bf
- Minimum recommended bend radius R = 150 mm - 5.9 in
- Maximum recommended length 5000 mm - 157.48
- Working temperature from -20 to 80 °C - from -4°F to 176°F
- Flexible polyurethane cable with 5 wires: 0.75 mm2 - 0.0012 in2 Ø external 5.2 mm - 0.20 in, Ø wire 1.55 mm - 0.06 in with both turning ends.
Custom requests or Questions, simply click here for a quick response. NOTE: All Shipping via EXPRESS Post.
